Air-Cooling Laser Welding Machine
Product Category
- Aviation Tools
- Aviation Fasteners
- PBM-A/B SERIES SPRING FASTENERS
- DS CYLENDERICAL BODY SPRING FASTENERS
- DP CYLENDERICAL BODY FASTENERS
- AB SERIES HEX BODY FASTENER
- BDN SERIES WING NUT FASTENERS
- DNS SERIES HEX BODY SPRING FASTENERS
- TR/BBS SERIES SPRING FASTENERS
- CB-CCN/CB-DDS
- TEMPORARY FASTENER INSTALLATION TOOL
- OTHER SERIES FASTENERS
- Aviation Drills
- Aviation Fasteners
- Hand Tools
- LASER MACHINE
- Cutting Tools
| Product Features |
|---|
| 1.The overall weight is less than 38kg, with a compact design and no chiller, resulting in a smaller volume; |
| 2.The output power can reach 1500W, and the welding penetration depth can reach 4mm; |
| 3.Based on 976nm pump technology, photoelectric conversion efficiency $\ge 42\%$; |
| 4.Single pendulum welding head with adjustable welding width; |
| 5.Unique air-cooled design, low power consumption, energysaving and environmentally friendly; |
| 6.Triple protection design with built-in air pressure detection device; |
| 7.Multiple operation modes, supporting tailor welding, overlap welding, fillet welding, vertical welding, etc |
| Items | Technical Parameters |
|---|---|
| Model | HLWM-1000/1500-AC |
| Output power | 1000W/1500W |
| Working mode | Continuous/Pulse |
| Output light wavelength | 1080±10nm |
| Output cable length | 1080±10nm |
| Output cable length | 5m/10m |
| Swing width | ≤5mm |
| Indicating light wavelength | 650nm |
| Output fiber interface type | QBH/QD |
| Working environment temperature range | 0~50 |
| Oscillation frequency | 0-300Hz |
| Supply voltage | 220VAC/50Hz/60Hz, |
